| Model | Configuration | Dimensions | Filter Frame Material |
Material | Filteration Rate |
Max Working Temperature |
Compatible Models |
|---|---|---|---|---|---|---|---|
| CHF-2222-40-62P | Mini Pleat | 220x220x40mm | Cardboard | Polypropylene | 45um 80% or above |
60℃ | CKU-060AD-ACC |
| CHF-2030-50-F1 | Mini Pleat | 200x300x50mm | Flame-retardant ABS | Polyester+PTFE | 0.3um 99% or above |
70℃ | CBA-1000TP1-DSA CBA-1500TP1-DSA |
| CHF-2525-50 | Mini Pleat | 250x250x50mm | ABS | Polypropylene | 0.3um 99% or above |
70℃ | CKU-060AD-ACC CBA-080AD CBA-080TP1(-V1) CKU-050 CKU-080AD(-V1) |
| CHF-3030-50 | Mini Pleat | 300x300x50mm | Polypropylene | PE+Polypropylene | 0.3um 99% or above |
70℃ |
CBA-500TP1(-V1) CBA-1200TP1 CBA-1600TP1 CKU-240TP1(-V1) |
| CHF-3535-70 | Mini Pleat | 350x350x70mm | ABS | PE+Polypropylene | 0.3um 99% or above |
70℃ |
CGU-250AD-ACC CGU-250AD-FB CBA-2400AT3 CMS-2600TP-P CMS-2600TP1 CMS-2600TP1-P CKU-450TP1(-V1)
|
| CHF-4040-30 | Mini Pleat | 400x400x30mm | Cardboard | PE | 45um 80% or above |
70℃ | CHP-1200AT3-ACC CHP-1600AT3 |
| CHF-3030-20 | Mini Pleat | 300x300x20mm | Cardboard | PE+Polypropylene | 45um 80% or above |
60℃ | CHP-1200AT3-ACC CHP-1600AT3 |
| CHF-3535-95 | Mini Pleat | 350x350x95mm | Aluminium | Glass Fiber | 0.3um 99% or above |
70℃ | CKU-750TP1(-V1) |
| CHF-3517-30 | Mini Pleat | 350x170x30mm | Cardboard | PE+Polypropylene | 0.3um 99% or above |
70℃ | CMP-2500AT3-A(-V1) CHP-1200AT3-ACC CHP-1600AT3 |
