| Model | Configuration | Dimensions | Filter Frame Material |
Material | Filteration Rate |
Max Working Temperature |
Compatible Models |
|---|---|---|---|---|---|---|---|
| HEP-1714-30 | Mini Pleat | 172x142x30mm | ABS | Polypropylene +PTFE |
0.3um 99.9% or above |
70℃ |
CBA-750TP1-DSA CHP-1600AT3 CHV-030AD CBA-1600TP1 CBA-2400AT3 |
| HEP-2525-50 | Mini Pleat | 250x250x50mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CKU-080AD-V1 CBA-080TP1-V1 |
| HEP-3220-69 | Mini Pleat | 200x320x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CBA-1000TP1-DSA |
| HEP-3030-69 | Mini Pleat | 300x300x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CKU-240TP1-V1 CBA-500TP1-V1 CBA-1200TP1 CBA-1600TP1 |
| HEP-3535-69 | Mini Pleat | 350x350x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ |
CKU-450TP1-V1 CBA-2400AT3 CMS-2600TP-P CMS-2600TP1 CMS-2600TP1-P |
| HEP-5040-80 | Mini Pleat | 500x400x80mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ |
CMP-2500AT3-A-V1 CMP-2200AT3-V1 CMP-3700AT3-V1 |
| HEP-1293-34 | Mini Pleat | 123x93x34mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CBA-1200TP1 |
| HEP-3225-69 | Mini Pleat | 320x250x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CBA-1500TP1-DSA |
| HEP-4040-69 | Mini Pleat | 400x400x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CHP-1600AT3 |
| HEP-3535-96 | Mini Pleat | 350x350x96mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CKU-750TP1-V1 |
| HEP-2720-69 | Mini Pleat | 270x200x69mm | Aluminium | Glass Fiber | 0.3um 99.97% or above |
70℃ | CBA-750TP1-DSA |
