| Model | Configuration | Dimensions | Filter Frame Material |
Material |
Filteration Rate |
Max Working Temperature |
Compatible Models |
|---|---|---|---|---|---|---|---|
| HDF-3535-120-F1-ZEO | Mini pleat+Cassette | 350x350x124mm | ABS+ Polycarbonate | Polyester + PTFE + SUS | 0.3um 99.9% or above |
60℃ | CBA-1000AT3-HC-DSA-V1 |
| HDF-3535-120-F1-RP-ZEO | Mini pleat+Cassette | 350x350x124mm | ABS+ Polycarbonate | Polyester + PTFE + SUS | 0.3um 99.9% or above |
60℃ | CBA-1000TP1-DSA |
| HDF-3535-176-F1-ZEO | Mini pleat+Cassette | 350x350x182mm | Aluminum + Polycarbonate | Polyester + PTFE + SUS | 0.3um 99.9% or above |
70℃ | CBA-1500AT3-HC-DSA-V1 |
| HDF-3535-176-F1-RP-ZEO | Mini pleat+Cassette | 350x350x182mm | Aluminum + Polycarbonate | Polyester + PTFE + SUS | 0.3um 99.9% or above |
70℃ | CBA-1500TP1-DSA |
| HDF-3030-120-F1-RP-ZEO | Mini pleat+Cassette | 300x300x125mm | Aluminum + Polycarbonate | Polyester + PTFE + SUS | 0.3um 99.9% or above |
70℃ | CBA-750TP1-DSA |
| HDF-3535-120-ZEO-DC | Mini pleat+Cassette | 350x350x126mm | Aluminum + Polycarbonate | ESD Carbon Fiber + PTFE | 0.3um 99.31% or above |
70℃ |
CHR-1200D CHR-1200D-KO |
| HDF-3535-166-ZEO-DC | Mini pleat+Cassette | 350x350x172mm | Aluminum + Polycarbonate | ESD Carbon Fiber + PTFE | 0.3um 99.31% or above |
70℃ |
CHR-2600D CHR-2600D-KO CHR-2600D-V |
